Ridewell Pressure Protection Valve - 1230060

Vendor: Ridewell

Part #: K861042

Regular price $66.00 $36.00

Ridewell 1230060 Pressure Protection Valve w/Check Seal

PPV w/Check Seal

Inlet Port = 3/8" NPT

Outlet Port = 3/8" NPT

Open: 70 PSI
Close: 60 PSI

Used: to assure a nominal pressure of 70 PSI. In the event of a system failure or a decrease in the valve's supply pressure, the valve will prevent further pressure loss or reverse flow.
Be sure to orient the inlet and outlet ports in the appropriate direction.
Mounting attitude is optional.

Replaces:
Euclid Number: ESL140270
Meritor Number: RSL140270
Sealco Number: 140270
